Basic Equipment

Measuring range

O2	0 … 21 %
NO(x)	0 … 1.000 ppm* overload up to 5.000 ppm (option)
CO (H2 compensated)	0 … 4.000 ppm* overload up to 10.000 ppm (option)
Differential pressure	at basic unit ± 100hPa, at remote control ± 200hPa
External pressure sensor	up to 40 bar (option)
Temperature	up to 650 °C or up to 1.100 °C (with suitable sensor)
Fluegas temperature	0 … 650°C (stainless steel tube) 0 … 1.100°C (inconeltube)
Flow	in conjunction with airflow cone
Relative humidity	3 … 98 %
Amount of leakage	0 … 8 l/h
External temperature sensor	K-type standard

Calculated values

Dew point	calculated °C
Losses	0 …99,9 %

Dimensions and other data

Gas conditioning	illuminated condensate trap, alternatively gas cooler
Sample gas flow monitoring	optional, standard with soot measurement
Flow velocity	with pitot tube 1 … 40 with vane 0,25 … 35 m/s
Soot measurement	optionally available as built-in feature
Combustion air temperature	0 … 100 °C
Housing	metal
Operating temperature	+ 5 … + 45 °C, max. 95 % RF, non condensing
Storage temperature	– 20 … + 50 °C
Power supply	grid 100 … 240 Vac / 50 … 60 Hz, 1,4 A, 12 V DC/5A
Battery capacity	basic unit 20 hours, with gas cooler 10 hours / remote control 30 hours
Weight	7,4 kg with 2 sensors, probe, power supply, case
Dimensions	470x314x235 mm (HxWxD)
TÜV approval	By RgG 296
4Pa-Test	optionally available
Data storage	internally 1MB or externally 2 GB
Bluetooth data transfer	optionally available
Data transfer	via USB cable, optionally via Bluetooth
PC-interface	mini-USB, optionally Bluetooth
Display	3,5″ TFT colour display
Pressure ranges	internally up to 1,5 bar (option) externally up to 40 bar (option)
